CLS630CX/D – 6″ High-Performance Coaxial Ceiling Speaker with Fire Dome

CLS630CX/D – 6″ High-Performance Coaxial Ceiling Speaker with Fire Dome

RM230.00

6″ high-output coaxial ceiling speaker with 70V/100V transformer, 8Ω input, fast-mount system and included fire dome.

SKU: CLS630CX/D Categories: ,

The CLS630CX/D is a high-performance 6″ coaxial ceiling speaker with transformer, low-impedance input and included fire dome for demanding distributed-audio installations.

Features

  • High-quality coaxial speaker with integrated 100V transformer
  • Elegant rimless design
  • Fire dome included
  • High output for wider coverage
  • Fast-mount design for easy installation
  • Durable ABS enclosure
  • Suitable for background music in homes, cafes, meeting rooms, supermarkets, restaurants and airports

Specifications are subject to change without prior notice.

Model

CLS630CX/D
Rated Power (100V)

7.5W / 15W / 30W
Low Impedance

60W / 8Ω
Rated Power (70V)

3.8W / 7.5W / 15W
SPL (1W/1m)

90dB
Max SPL (1m)

103dB
Frequency Response

50Hz–20kHz
Driver

6″ coaxial
Product Material

White ABS housing; white aluminium grille
Cut-Out Hole Size

205mm
Product Dimension

235mm (W) x 160mm (H)
Product Weight

2.5kg
Packing Dimension

240mm x 240mm x 170mm
Packing Weight

3.2kg
Master Pack Dimension

500mm x 500mm x 375mm
Master Pack Weight

21.5kg
Master Pack Quantity

8 pieces
